The Lingan Bag-Based Cell Thawer
Features
Core Technologies:
1.Infrared Thermal Imaging Recognition: Enables panoramic monitoring of cryobag cell changes, scanning overall temperature variations to avoid incomplete data from single-point collection；
2.Dry Heating Technology: Water bath-free design utilizing metal or air bath heating to prevent water contamination and osmotic pressure changes；
3.Intelligent Temperature Control Algorithm: Equipped with 6 standard thawing programs, supports customized algorithms, and automatically determines the thawing endpoint via real-time temperature monitoring；
4.Data Traceability: Records thawing curves and generates unmodifiable CSV files compliant with GMP standards.
Parameters & Compatibility:
1.Capacity: Compatible with 25 mL–1000 mL cryobags (actual cell filling volume: 10 mL–275 mL)；
2.Point Temperature Monitoring: Each bag chamber incorporates multiple probes for real-time temperature tracking to ensure homogeneous thawing；
3.Safety Features: Multiple alarm mechanisms (e.g., overtemperature, liquid leakage), easy maintenance, and resistant to disinfectant corrosion；
4.Suitable Environments: Can be used within clean benches or sterile isolators.
| Items | Specification | Note |
| Cat No. | LA-C1000 | |
| Thaw time | 5-10 min | |
| Infrared thermal imaging camera | Panoramic scans record temperature changes | Provides complete thaw data |
| Infrared probe | Accuracy ≤±0.1℃ | 5 pcs |
| Temperature control accuracy | ≤±1.0℃@50℃ | |
| volume | 25~1000ml | |
| display | 1-60rpm | |
| display | Color 7-inch (800*480) touch screen | |
| USB flash drive interface | 2 pcs | Log Export |
| Size | 373*404*302(mm) | |
| Weight | 15KG | |
| Maximum power | 600W | |
| power supply | 220V | |
| Sterilization method | whole machine | Internal/external UV can be customized |
